12V LiFeP04 Battery
3 Lithium Ferro Phosphate Batteries 12 V / 60Ah / 100Ah / 200Ah with Bluetooth
For a connection through Bluetooth with the batteries, we must first carry out the following operations.
Scan the QR code to download the app. Bluetooth can be activated by downloading the device.
Activate GPS positioning before connecting Bluetooth
As we can see it is very simple and straightforward.
Models of LiFePo4 Lithium Ferro Phosphate Batteries with connection via Bluetooth
12V and 60Ah LiFePo4 (ref. BLF-26)
• Weight 6.8kg
• Measures 240 x 175 x 210mm
• 12.8 V and 60 Ah total 760 Wh
• Offers the performance of a traditional battery with a weight of 35kg
• Maintenance-free throughout the useful life
12V and 100Ah LiFePo4 (ref. BLF-27-SP)
• Weight 11kg
• Measurements: 340 x 175 x 220 mm
• 12V 100Ah battery, a total of 1,200 Wh
• Serial or parallel connection
• Offers the performance of 2 traditional batteries with a weight of 60kg.
• Maintenance-free throughout the useful life
12V and 200Ah LiFePo4 (ref. BLF-28)
• Weight 20kg
• Measures 530 x 238 x 220 mm
• 12.8V and 200Ah battery, a total of 2,500Wh
• Provides the performance of 4 traditional batteries with a weight of 120kg
• Maintenance-free throughout the useful life
Common Features of 12V LiFePo4 Batteries
Designed for use in caravans, nautical, robotics, camping, isolated homes, solar battery banks and wherever an accumulation battery is required.
• 5 year warranty
• The performance curve of the 12V batteries maintains a continuous voltage delivery during 90% of the discharge.
• Low level of load resistance.
The ideal charge range is 0.2C, that is, a charge of 20% every hour. They can be charged up to 0.5C 50% per hour. Taking into account that it is not usual to charge 100% in each charge. The ideal discharge rate is 0.10C to 0.25C.
assumes use between 10 and 4 hours. It is possible to reach a rate of 0.5C, discharge in 2 hours.
Estimated lifespan between 10-15 years, depending on the factors of use, type of charges and discharges, etc.
To help extend the life of 12V Lithium Ferro Phosphate batteries, it is advisable not to exceed 90% of their charge capacity and 20% discharge capacity on a regular basis.
LiFePo4 batteries have no memory effect and can be used immediately after charging, the self-discharge rate is very low, depending on the ambient temperature it is between 1.5% and 3% per month.
They do not contain heavy metals or contaminants, the decomposition temperature of lithium iron phosphate is around 600ºC, thus offering maximum safety and stability.
